Product Summary

The LQW15AN5N6C is a Chip Coil. It consists of air core chip coil using a miniature alumina core. The device has high Q value in high frequency range and high self resonant frequency. It is suitable for high frequency circuits which are used in telecommunication equipment.

Parametrics

Reference Data: (1)Inductance:5.6 ±0.2nH; (2)Test Frequency:100mHz; (3)Rated Current:800mA; (4)DC Resistance:0.051ohm max.; (5)Q(min.):30; (6)Test Frequency:250MHz; (7)Self Resonance Frequency (min.):8.0GHz; (8)EIA:0402.

Features

Features: (1)Horizontal winding structure enables tight inductance tolerance(+-0.2nH, +-3%); (2)The subminiature dimensions (1.0x0.5mm) allow high density mounting; (3)The high self resonant frequency realizes high Q value and stable inductance at high frequence; (4)Low DC resistance design is ideal for low loss, high output and low power consumption; (5)Resin-coated surface enables excellent mounting.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LQW15AN5N6C10D
LQW15AN5N6C10D
Murata
RF Inductors 5.6 NH +-.2NH
Data Sheet
0-1: $0.16
1-10000: $0.10
10000-20000: $0.08
20000-30000: $0.08
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LQW15AN10NG00D
LQW15AN10NG00D
Murata
RF Inductors 10 NH +-.2NH
Data Sheet
0-1: $0.17
1-10000: $0.08
10000-20000: $0.08
20000-30000: $0.07
LQW15AN10NH00D
LQW15AN10NH00D
Murata
RF Inductors 0402 10nH +/-3% DCR 0.17ohm
Data Sheet
0-1: $0.17
1-50: $0.15
50-100: $0.14
100-1000: $0.09
LQW15AN10NJ00D
LQW15AN10NJ00D
Murata
RF Inductors 10 NH 5%
Data Sheet
0-1: $0.16
1-50: $0.14
50-100: $0.13
100-500: $0.10
LQW15AN11NG00D
LQW15AN11NG00D
Murata
RF Inductors 11 NH +-.2NH
Data Sheet
0-1: $0.17
1-10000: $0.08
10000-20000: $0.08
20000-30000: $0.07
LQW15AN11NH00D
LQW15AN11NH00D
Murata
RF Inductors 11nH 3% 100MHz
Data Sheet
0-1: $0.17
1-50: $0.15
50-100: $0.14
100-1000: $0.09
LQW15AN11NJ00D
LQW15AN11NJ00D
Murata
RF Inductors 11nH 5% 100MHz
Data Sheet
0-1: $0.16
1-50: $0.14
50-100: $0.13
100-500: $0.10
