Product Summary

The LQW15AN27NJ is a Chip Coil. It consists of air core chip coil using a miniature alumina core. The device has high Q value in high frequency range and high self resonant frequency. It is suitable for high frequency circuits which are used in telecommunication equipment.

Parametrics

Reference Data: (1)Inductance:27±5% nH; (2)Test Frequency:100mHz; (3)Rated Current:280mA; (4)DC Resistance:0.52ohm max.; (5)Q(min.):25; (6)Test Frequency:250MHz; (7)Self Resonance Frequency (min.):3.5GHz; (8)EIA:0402.

Features

Features: (1)Horizontal winding structure enables tight inductance tolerance(+-0.2nH, +-3%); (2)The subminiature dimensions (1.0x0.5mm) allow high density mounting; (3)The high self resonant frequency realizes high Q value and stable inductance at high frequence; (4)Low DC resistance design is ideal for low loss, high output and low power consumption; (5)Resin-coated surface enables excellent mounting.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LQW15AN27NJ00D
LQW15AN27NJ00D
Murata
RF Inductors 27 NH 5%
Data Sheet
0-1: $0.16
1-50: $0.14
50-100: $0.13
100-500: $0.10
